Description

The Balystik EU Coupler is a rugged quick-disconnect fitting designed for European-style HPA systems. Featuring a standardized 1/8″ NPT male thread and a durable black-anodized finish, it provides a secure, leak-free connection between your remote line and HPA reservoir or regulator. Its spring-loaded collar ensures rapid, one-hand coupling and uncoupling under full pressure, making field swaps and line routing effortless.

Technical Specifications

  • Thread Standard

    • Male Thread: 1/8″ NPT (National Pipe Tapered)

    • Coupler Interface: European quick-disconnect (Ø9 mm push-to-connect)

  • Materials & Finish

    • Main Body: CNC-machined aluminum alloy, hard-anodized black

    • Internal Seals: Viton® O-rings for high-temperature, high-pressure resistance

    • Spring & Balls: Stainless steel

  • Performance Ratings

    • Maximum Working Pressure: 300 bar (4,350 psi)

    • Recommended Operating Range: 60–200 bar (870–2,900 psi)

    • Burst Pressure: > 500 bar (> 7,250 psi)

    • Flow Capacity: 12 l/min @ 100 bar

  • Dimensions & Weight

    • Length (including collar): 45 mm

    • Collar Diameter: 20 mm

    • Weight: 45 g

Compatibility

  • HPA Systems: Any European-style remote line or fill station with a matching quick-disconnect socket

  • Reservoirs & Regulators: Tanks, bulk-fill stations, and regulators with 1/8″ NPT female port

  • Airsoft Platforms: All makes and models using common Ø9 mm push-to-connect fittings

Installation & Use

  1. Prepare Port
    Ensure the 1/8″ NPT female port is clean and thread-seal tape is applied.

  2. Thread In
    Hand-tighten the coupler into the port, then give a ¼-turn with a wrench—do not over-torque.

  3. Connect Line
    Push your European quick-disconnect socket fully onto the coupler until you hear a click.

  4. Verify Seal
    Slowly pressurize the system and check for leaks; tighten further if necessary.

  5. Disconnect
    Pull back the collar under pressure for an instant, tool-free removal.

Key Benefits

  • Rapid Coupling: Spring-loaded design for one-hand operation, even at full pressure

  • Leak-Free Reliability: Precision machining and Viton® seals ensure zero blow-outs

  • Wide Pressure Range: Suited for everything from low-pressure fills to high-pressure tanks

  • Compact & Lightweight: Minimal bulk on your line, for unobtrusive routing

  • Corrosion Resistance: Anodized finish protects against moisture and wear

Package Contents

  • 1 × Balystik EU Coupler with 1/8″ NPT Male Thread (Black)

  • 1 × Spare Viton® O-ring

  • 1 × Thread-seal tape strip

  • 1 × Quick-start usage card

Equip your HPA setup with the Balystik EU Coupler for fast, secure, and maintenance-free connections every time.
